Small and lightweight equipment

Simple and intuitive user-friendly interface-the touch control panel is clear and easy to use

internal mute  water

Internal mute water peristaltic pump that is compatible with disposable water tubing up to 110ml/min

Water adjustment

A small screen can be used to adjust water volume and also provide real-time temperature

Function of programs

Customization Torque Adjust Memory Function

Ball Bearings from Germany

Brushless and noiseless high-quality Swiss motor

Fiber-optic illumination

Powerful torque up to 80Ncm

Water flow adjustment switch

           Program switch

           Rotating direction switch

          Speed control

                 LED screen

Rotation Speed Range: 300-40,000rpm

Torque Range: 5Ncm-80Ncm

Gear Ratios: 16:1 20:1 27:1 1:1 1:2 1:4 1:5

Max Pump Output: 110ml/min

Main Unit Dimensions : 236mm *215mm *77mm

Motor Dimensions : 22mm*L108mm

Handpiece Dimensions: 22mm *L96mm

Motor Weight: 90G

Handpiece Weight: 80G

Power Supply: Ac220v 50-60Hz

Length: 2m

Motor Type: Swiss Made Brushless Motor

Handpiece Type: Built-in with Germany Made Bearing
